I Judge People By Their Grammar and Knowledge of Phenol
Posted by Paul on March 10th, 2007
Some commenters in a previous thread took umbrage at the fact that I admit to judging people by their grammar. Well, I do, and I’m not going to change anytime soon. I’ll put poor grammar on par with poor hygiene, dressing like a slob, and bad table manners—while they don’t automatically invalidate a person’s ideas, they will cause me to treat anything the person says with more skepticism than usual. With respect to the four errors I found in the first paragraph of this recent paper from Org. Lett., the misplaced apostrophe in “Evan’s” was the most aggravating. While the chemistry in the paper was good, as The Chem Blog has noted, the authors’ lack of attention to detail was borderline disrespectful. I expected more from one of the most storied labs in synthetic organic chemistry.
A lot of people will complain, “So what if I make a few mistakes? Why don’t you focus on the ideas?” That’s the thing: I want to focus on your ideas, so why don’t you stop whining and learn to write properly? The rules of grammar are not up for discussion—just follow them out of courtesy to your readers. Grammatical errors are distracting and will cause them to lose sight of what you’re writing. If you are someone who has no trouble reading documents riddled with mistakes, that’s great, but when you are writing, you aren’t writing for yourself.
While grammar shouldn’t be the sole criterion for evaluating intelligence, I will admit to judging some things by a relatively obscure set of criteria. For instance, I have a list of favorite subjects for judging textbooks and course packets. One of the first things I do to determine the quality of a sophomore organic textbook is to look in the index for phenol. As you all know, phenol is more acidic than “standard” aliphatic alcohols. If you took a survey, most people would ascribe this fact to a resonance effect by drawing the following structures:
There are a number of variations on this theme, including drawing out all of the unhybridized p orbitals and showing that an orbital on oxygen containing a lone pair can overlap with the pi system, thereby allowing for increased delocalization of the extra negative charge density.
It turns out that an inductive effect—not a resonance effect—is the predominant reason for the increased acidity of phenol relative to aliphatic alcohols. Whereas aliphatic alcohols have a C(sp3)—O bond, the carbon to which the hydroxyl group is bonded in phenol is sp2 hybridized. The increased s-character of the carbon orbital used to form the C—O bond makes it more electron withdrawing, which leads to greater stabilization of the conjugate base of the alcohol. For the purpose of comparison, look at the pKa of phenol compared to that of enol tautomer of acetone:
Even though you can only draw two resonance forms showing delocalization of the extra negative charge in the conjugate base of the enol (vs. four for phenol), the acidities of the two protons differ by less than an order of magnitude. For those interested, these data come from Evans’ Chem 206 lecture notes (Lecture 20, restricted access), where the point is hammered home in glorious detail. Professor Evans’ PowerPoint slides should be framed and displayed in the Smithsonian.
While we’re discussing phenol and errors, let me also use this example to illustrate one of the main problems with Wikipedia. Wikipedia is great, but it is home to a number of edit-happy users who think they know more than they actually do. If you look at the discussion page for phenol, someone actually addressed the resonance vs. inductive effect argument, but was unceremoniously (mis)corrected by another user, who references an incorrect explanation on the Internet. Thus, the main article (as of today) gives the incorrect (resonance > inductive) explanation:
Phenol has a limited solubility in water (8.3 g/100 ml). It is slightly acidic: the phenol molecule has weak tendencies to lose the H+ ion from the hydroxyl group, resulting in the highly water-soluble phenoxide anion C6H5O−. Compared to aliphatic alcohols, phenol shows much higher acidity; it even reacts with NaOH to lose H+ whereas aliphatic alcohols do not. This is due to orbital overlap between the oxygen’s lone pairs and the aromatic system, which delocalizes the negative charge throughout the ring and stabilizes the anion. This effect is attenuated, however, due to oxygen’s relatively high electronegativity. [1]
God knows that we in the chemical blogosphere love the Wikipedia, but read it with skepticism.
This concludes today’s lesson. Your homework for the weekend is to find all of the grammatical errors in this post. For extra credit, find an error in a chemistry article on Wikipedia, fix it, and brag about having done so in the comments. Class dismissed.
March 10th, 2007 at 6:55 am
Since you make opinion of people based on their usage of grammer, I think i should better stop commenting (and learn English, instead, using that time) to restore my dignity. It is too late for me my dear…
March 10th, 2007 at 7:32 am
Have you considered that many people speak 3-4 languages and the fact that they can write/speak English (in addition to 2-3 other languages) almost correctly is a pretty great achievement already?
How is your, say, Spanish or French? Any spelling mistakes?
March 10th, 2007 at 8:16 am
I judge people by the units they use. Mr. Evans used kcal, so he lost
I am asking myself if you can accurately and precisely determine the pKa of acetone-enol. Besides that it does not convince me that acetone lies on a regression line made from two data points (actually the fact that phenol is to the left of that line shows a conjugation effect).
Anyway it’s an interesting thing that I should remember.
March 10th, 2007 at 8:19 am
My thoughts precisely. Expecting that anyone in the world would be capable to write an article in perfect English is utopic. Criticising the foreign post-doc who wrote the paper for not being 100% grammatically correct is a bit arrogant. Blaming the (probably very busy) supervisor for not correcting each article word-by-word is not fair.
But overlooking the work of the Editorial Office in letting this paper come out without taking an appropriate look at grammar is somewhat surprising, especially coming from you… as I see it, the ACS Publications division receives more than enough money to pay people to do this. Stop nagging the authors or feeling “disappointed” because the lab it comes from “should have done better”.
March 10th, 2007 at 8:22 am
and I judge people by how they use “maths”: R = OR is nothing but a contradictory statement. Just like it is with grammar: everyone knows what is meant but it doesn’t look nice and it doesn’t seem like the person spent a lot of time and thought writing the text.
March 10th, 2007 at 8:43 am
Excellent. The bleeding hearts are out in force, armed with low expectations and plenty of excuses.
There is certainly enough blame to go around; I have no problems including the copy editors at ACS Pubs.
And I’m not saying that a resonance effect is completely absent, just that the inductive effect clearly predominates.
March 10th, 2007 at 9:51 am
How can you say the inductive effect clearly predominates based on that one example of the acetone enol? In that case, it seems possible that the one resonance structure of the enol could be better than all of the resonance forms of phenoxide. That is, each of the resonance structures of phenoxide breaks the aromaticity of the ring, unlike with the enol, which might make them poorer contributors to the overall hybrid than the lone resonance contributor of the acetone enolate. (Common misconception: 2 resonance structures is not always better than 1; it depends on their overall contribution to the hybrid). I’m not saying you’re wrong about the inductive effects, but I think it’s difficult to say this definitively with only the two pKas in hand.
March 10th, 2007 at 10:28 am
Wiki should be used as nothing more as a “portal” for quick ref then further lookup of something.
We had this debate at Milo’s musings… a while ago.
Paul - why not go impart some of your glorious knowledge onto the wiki?
March 10th, 2007 at 11:15 am
I never trust a wiki I didn’t write myself.
Mitch
March 10th, 2007 at 12:01 pm
A (putative) American who cannot speak and write grammatical English is a dunce. American zero-goal education celebrates the empowerment of stupidity - every child left behind. Elitism insists the better is preferable to the worse. Uncle Al is an elitist.
Anybody who publishes in English should/must run it by an English editor. English is not pidgin.
Why stop with sp2? Compare C-H acidities in methane, ethylene, benzene, and acetylene. #C-OH is respectably acidic on paper (# being a triple bond). If somebody likes ethene and ethyne better, “polythene” isn’t New World patois.
March 10th, 2007 at 12:02 pm
I agree with Karl. While Evan’s (tee hee) makes the valid point that phenol’s acidity is not primarily due to resonance, I don’t think it’s valid to say it’s there is no resonance effect. Evans unforatunately leaves out the case of o,p- vs. m-nitrophenol, which demonstrates a possible resonance effect. The pKa of o,p-nitrophenol is around 7 while m-nitrophenol is around 8- an order of magnitude difference. Of course, the inductive effect appears to have a higher impact on the overall acidity of nitrophenols as the pKa of phenol is two orders of magnitude higher than m-nitrophenol, there appears to be a resonance effect as well. Evans’ point is correct, but you’re taking it too far. Anslyn and Dougherty says that “it is often difficult to separate resonance from inductive effects,” and that’s where I stand as well. As Karl hints at, resonance also tends to be a more complicated issue than the brushjob given to sophomores.
March 10th, 2007 at 1:04 pm
This is not entirely related, but felt a strong need to communicate this with someone.
A few weeks ago I created an entry in Wikipedia [Protocol (natural sciences)], and when I looked at it today, it was completely different both in content and philosophy to what I had originally written! It has developed a life independant of me.
This is the first time that I have experienced this so am a bit stunned. Was definitely (initially) distrustful of the new content, because of the new author’s grammar, but maybe it just needs to be copyedited a bit…
March 10th, 2007 at 1:36 pm
This sounds like any academic debate Bronwen!
March 10th, 2007 at 1:40 pm
Paul: Just how picky are you about grammar?
(I blame the copy editors, by the way)
March 10th, 2007 at 2:10 pm
I agree with Karl and Excimer - it’s certainly not wrong to draw those resonance structures. It’s another carbon removed, but to compare the inductive effects of sp2 vs sp3, consider acrylic acid (pka 4.25) and propanoic acid (pka 4.86), so, at that distance, the inductive effect buys you 0.6 pka units, when it’s right next to the charged atom it’s going to be a bigger effect, but I bet it doesn’t account for the full difference of 6…
March 10th, 2007 at 2:12 pm
Karl: Are you sure you are breaking aromaticity since the electrons are technically still in the conjugated p-orbital system. Although, now there is that destabilizing extra electron.
Mitch
March 10th, 2007 at 2:13 pm
I expect flawless prose in formal documents like scientific papers. I generally care much less about blog posts/comments, e-mails, and spoken conversation. A lot of times you have to use weird grammar and punctuation for something to read the same way you would say it. Basically, anything that you proofread more than three times should be error-free. And, of course, some violations are more egregious than others. So relax, I don’t read JACS or C&EN with a red pen. It’s just that when someone strings together a number of errors (like four in one paragraph), it is difficult not to notice.
March 10th, 2007 at 3:14 pm
Mitch: Formally the resonance structures of phenolate are not aromatic by Huckel’s rules since they (formally) have 7 electrons in the ring (4 from the two double bonds, 2 from the lone pair, plus one electron from the double bond to oxygen).
March 10th, 2007 at 3:54 pm
Karl: I understand. I personally wouldn’t say adding a single electron “breaks” aromaticity though, but I know what angle your coming from.
Mitch
March 10th, 2007 at 7:37 pm
Face it, Organic chemistry is hard for most students to learn. There are several reasons for this. One solution is to over-simplify things. These are occasionally gross oversimplifications that cause us teachers to cringe when we teach them. But, we have to start somewhere. There is so much to learn at the sophomore level that we just can’t get into all of the details. The phenol resonance/inductive effect is just one of many examples of things we “lie” about at the sophomore level. Usually by the time these students reach the advanced organic courses, we can talk more about the realities. Then it gets a lot more fun. Sadly, most students never make it that far. The bottom line is that Organic chemistry is so broad and complex, we are forced to make unfortunate sacrifices.
March 10th, 2007 at 10:48 pm
Just for coincidence, I saw the Meistersingers of Nuremberg today at the Met for the first time in my life. We all are quite good, or at least, we hope so. But, the character of Beckmesser there was really somewhat inconvenient. So, what is now the matter for an elite student from the world’s richest university, with an absolutely German sounding proficience (Bracher), to explain what it is all about ??
March 10th, 2007 at 10:55 pm
provenience, I wished to say, you almost see what the problem is
March 10th, 2007 at 11:13 pm
And, while we don’t think we are animals, we still like the movie” March of the Penguins”. They have no Harvard grade nor grammatical problems, but they find and caress their offspring, it seems, all over the world.
March 11th, 2007 at 12:00 am
This may be a related question:
How many of you offer grammar suggestions in articles you are peer reviewing?
(disclaimer: this is a symbolic question since we all know that only PI’s see and review papers)
Many of my colleagues go line-and-item on many of the papers. Personally, I only worry about
the content of the paper because I think the grammar is the editor’s job. If it is a mess I simply
say so and do not go into detail.
March 11th, 2007 at 1:22 am
the forms must be obeysed… else…
something different might happen!!!!
and i know I speak for all when i say we must crush it!!!
March 11th, 2007 at 1:49 am
mistake 1: umbrage is perhaps the wrong word–and one wouldn’t take umbrage AT a fact, i suppose they would take umbrage UNDER a fact…
March 11th, 2007 at 3:09 am
Anon: There is nothing wrong using the word “umbrage” in this context. Also, “at” is the correct preposition, in that you do “take umbrage at” something.
For more info, refer to the Random House and Merriam-Webster unabridged dictionaries. Thanks for playing.
March 11th, 2007 at 3:18 am
I stand corrected. I should also learn not to try and outpedant the master.
March 11th, 2007 at 12:17 pm
Judging by someone’s grammar is not a good idea…especially when it comes to speech itself. Sure, in a professional setting such as a journal article, one should expect a degree of coherence in writing, but the so-called rules of grammar are NOT absolute and not rigid. Grammar itself is a human construction - period. It is not an inherent property of languages…its a property tacked on by humans. Languages come and go, changing all of the time, but grammar is supposed to never change. Some of those grammar books that are the “authority” on what one should say, do, and write are themselves pretty antiquated. People just don’t realize that languages are not uniform. Just because someone does not speak grammatically correct does not mean that you are a better person than they are. There are much better ways to judge a person than by that.
As for scientific literature, I would expect the manuscript to go through a rigorous editorial process, and it is likely that did not occur if there are errors in the paper. Considering there are people reading the papers (or at least possibly reading for most) who come from a wide variety of language backgrounds, it is a must.
The phenolate anion certainly had aromatic character to it. It may not be a pure case of an aromatic compound according to the “rules” but then again, there are other compounds that should not be aromatic and in fact sorta act like they are. And of course, there are degrees to aromaticity.
And I agree, it can’t be a case of pure induction. The resonance has to have some sort of effect even if it is not the major one.
March 11th, 2007 at 4:11 pm
The closest thing to a mistake I see is the comma in this compound predicate. Although I wouldn’t have used the comma, one could certainly make an argument for it.
“If you look at the discussion page for phenol, someone actually addressed the resonance vs. inductive effect argument, but was unceremoniously (mis)corrected by another user, who references an incorrect explanation on the Internet.”
From the Chicago Manual of Style:
6.34 Compound predicate
A comma is not normally used between the parts of a compound predicate—that is, two or more verbs having the same subject, as distinct from two independent clauses—though it may occasionally be needed to avoid misreading or to indicate a pause.
March 12th, 2007 at 10:05 am
Does this explaination account for the acidity of p-nitrophenol (pKa 7.1)? I would guess that is it was predominatly an inductive effect, as asserted, then the NO2, which is 4 sigma bonds away would have a minor effect on the acidity of the -OH. Am I missing something obvious here?
March 12th, 2007 at 11:22 am
Imperator,
I don’t think grammar is inherent to thought or language, but it is a useful system of conventions. When one writes, one writes to be understood by others, and it makes sense to play by the same set of rules (which is what grammar provides). There are enough misunderstandings based on factual misunderstandings, differences in context, implication, and other issues to add another method of misunderstanding to the mix, particularly when the ability to minimize grammatical mistakes is readily available. Second, if one can’t be bothered to run grammar and spellcheck on something published for one’s professional peers, readers might wonder how much effort the author put into anything else in the paper. Finally, journal articles are written not just for now but for the future as a part of a repository of chemical knowledge; following the rules of grammar helps people in the future to understand what you have said now. Informal, unwritten conventions are not derivable from those rules and, unless they are adopted by people in general, are likely to be misunderstood by future readers of your paper.
I wonder if the sloppiness in grammar doesn’t correlate in part with some authors’ willingness to see papers as a means to their own aggrandizement rather than as a way to communicate useful results to others.
March 12th, 2007 at 11:29 am
I think a lot of people are missing the point about what Evans is saying about phenol, i.e. it is primarily an inductive effect. Organic chemists tend to place too much emphasis on the orbital portion of the wave equation and forget about the electrostatic portion. This doesn’t mean that there is no resonance effect, it’s just smaller than the inductive effect. Putting nitro substituents increases both inductive withdrawing (even in the para position), but the nitro group itself gives resonance stablization to the negative charge as well. In other words, the coefficients on the electrostatic component of the generalized wave equation increase, but the orbital contribution increases even more for para-nitrophenol. You can model all of this easily in Spartan. Map out the orbitals and also check out the electrostatic charges.
March 12th, 2007 at 11:32 am
so how many bonds does a sulfone have?
March 12th, 2007 at 11:46 am
Poor grammer in published work is painful, but not really more so than the poor writing that it generally accompanies. Glance through this famous Orwell essay and then fantasize about how much easier all of our lives would be if scientific papers followed his rules.
http://mla.stanford.edu/Politi.....nguage.pdf
Oh, the native language of the authors is no excuse. I have yet to find a University without an English department full of starving grad students. They’d probably edit a paper for a pizza, but submitting a paper that truly does allow a reader to focus on the ideas should be worth a lot more.
March 12th, 2007 at 1:30 pm
How do they calculate the pKa of a proton on an enol?
March 12th, 2007 at 1:30 pm
99.9% of all organic chemistry papers break Orwell’s rule #4: Never use the passive when you can use the active.
PS: the supplementary info of that Org. Lett. paper by Trost is full of mistakes too. A bit embarrassing coming from a member of the paper’s advisory board…
March 12th, 2007 at 3:00 pm
So, Paul, which sophomore textbooks are up to snuff when it comes to phenol acidity? Aside from Evans’ 30/206 notes and a brief aside in Anslyn and Dougherty, I can’t say that I’ve seen a textbook go into this.
March 12th, 2007 at 4:09 pm
Anslyn and Dougherty is a wonderful text, isn’t it?
As for sophomore texts, I have yet to see a nice treatment of the acidity of phenol. I think that part of the reason is what Chemgeek brings up in #20: when teaching intro, we don’t want to lose sight of the forest for the trees. That said, the subject should be glossed over instead of explained incorrectly (using resonance as the primary reason).
Wade (3rd ed.) and Loudon (see Evans’ note) completely s— the bed when it comes to phenol acidity. Jones (1st) ignores the issue in the text, but it is a practice problem, and the solutions manual bollocksed it up. For my money, Jones is geneally ahead of the curve on most of these issues. He does things like explain the importance of stereoelectronic and solvation effects in explaining trends in the acidities of alcohols, when most other authors attribute the trend to an inductive effect, saying “alkyl groups are electron donating.” If I were to teach sophomore organic, I’d make my own coursepack, but would have Jones as the textbook. His explanations and practice problems are, in general, quite good.
March 12th, 2007 at 4:26 pm
Hap: I agree totally.
Phlogiston: Thanks for writing that out. The point, everyone, is not that there is no resonace effect, just that the observations are probably best primarily attributed to an inductive effect.
Pi*: Yeah, those S=O bonds aren’t “double bonds” in the same way that C=C double bonds are.
SSBiochem: Thanks for the link. I saved a copy of the pdf.
J: I actually looked around for that (not thoroughly) but couldn’t find anything. I have a guess, but will look further before polluting google with incorrect info.
March 12th, 2007 at 9:16 pm
Anyone who wishes to meet me at a Wolfiade ? (You don’t know what this is ?? gee…)
there is one in New York next week, see
http://www.acfny.org/downloade.....downl=true
March 12th, 2007 at 9:32 pm
Wolfie, you just made the 1000th comment in the history of this blog. I had a bad feeling it would be you.
March 12th, 2007 at 9:37 pm
Dammit. That means I was 999! Oh well, it’s only appropriate that you’re 1001.
March 12th, 2007 at 9:38 pm
No wait, it’s the other way around. Still, I feel like I’m part of history.
March 12th, 2007 at 10:41 pm
records are for the record, just take it as such
March 13th, 2007 at 3:53 am
who posted comment 666 then?
March 13th, 2007 at 7:55 am
what about comment # 69?
March 13th, 2007 at 8:32 am
Every time I post, it’s comment 666.
March 13th, 2007 at 2:19 pm
Speaking of grammar, Prof. Evans in his handout says “Lets calculate…” instead of “Let’s calculate…”
The apostrophe remains elusive for many.
March 13th, 2007 at 9:01 pm
So, Uncle Al and Paul;
Since accuracy is of primary concern to you both, do you think a citizen of Mexico, or Canada, or Peru should be offended by your using the word “American” to refer exclusively to denizens of the U.S.A.?
Just wondering. Bad grammar is not the only thing that drives me nuts!
March 13th, 2007 at 9:17 pm
Look up “American” in the dictionary. Using it to refer to things associated with the United States is perfectly acceptable. Also, why are you picking on me? I didn’t even use the word in this post.
Why do you hate me?
March 13th, 2007 at 10:52 pm
I think Penny Arcade could teach us a thing or two about punctuation.
March 14th, 2007 at 9:58 am
Speaking of pKa values, I find it strange that many organic chemists are obsessed with pKa’s measured in water or DMSO while most of their reactions (where these things matter) are actually performed in, say, THF or dichloromethane.
In any case, the Evans explanation is too simplistic. In fact, the standard textbook explanation is most likely to be correct, for the following reasons:
1) If electronegativity (in this case, sp2 vs. sp3 hybridization) were the key to acidity, one would expect acidities to drop in the series HF - HCl - HBr - HI. Exactly the opposite is observed, with HI being strongest although I is the least electronegative element.
2. Benzoic acid is only slightly more acidic than acetic acid (0.5 pKa units). Stu (#15) mentions acrylic acid vs. propanoic acid, where the difference is of equal magnitude.
3. If the electronegativity explanation were valid, the reason for the higher acidity of carboxylic acids vs. enols and phenols should lie in the higher electronegativity of oxygen in the carboxylic acids (O=C-O-H) vs. enols (C=C-O-H). However, in the gas phase, the acidities of phenols approach those of carboxylic acids. p-Nitrophenol is in fact slightly more acidic than p-nitrobenzoic acid in the gas phase!
See: http://dx.doi.org/10.1021/jp046990i
March 14th, 2007 at 3:01 pm
53.1) Isn’t solvation the big difference here, or are the acidities in the gas phase? In solution, the solvation energies overwhelm the effect of electronegativity (with fluorine, the electronegativity also increases the hydrogen bonding which alters the solvation).
53.2) Inductive effects decrease with distance - the sp2 carbons aren’t at the sites of acidity but another carbon away, which should decrease their effects on acidity accordingly.
53.3) Doesn’t the similar acidity of p-nitrophenol and p-nitrobenzoic acid argue more, not less, strongly for an inductive (or solvation) explanation? Carboxylic acids are nearly the ideal situation for selective resonance-based stabilization of the anions over the free acids while enols and phenols are less optimal (since the resonance forms of the anions aren’t equivalent). While there are a greater number of resonance forms to stabilize a negative charge in phenolates than in carboxylates, the resonance forms aren’t as good and should offer less resonance stabilization to the phenolate (in addition to breaking aromaticity). If phenols and carboxylic acids are of similar acidity in the gas phase, that should imply that the difference in resonance energies has little effect on the differences in acidity.
March 14th, 2007 at 6:13 pm
Part II.
3) Why should the delocalization of the negative charge be less effective in phenols than in carboxylic acids? Computationally it has been found that there is significant delocalization in the phenolate ion, including shortening of the C-O bond relative to PhOH, implying significant pi delocalization in the phenolate anion:
http://dx.doi.org/10.1021/ja993730j
This shortening is also evident in X-ray structures (typically for phenols, CCDC PHENOL03, the C-O is ca 1.37 Å, for phenolates, CCDC ROQFEI01 is a PhONa, the C-O is ca 1.28 Å, this value of course varies between different phenolate salts and solvated complexes).
Of course the pi delocalization is quite effective in carboxylate anions, and this naturally explains carboxylic acids are - indeed - acids. However, to argue that phenolate anions are somehow less delocalized simply because its “resonance structures” look more awkward does not constitute a very convincing argument.
A recent study by Holt and Karty
http://dx.doi.org/10.1021/ja020803h/
addresses the gas phase acidities of formic acid, vinyl alcohol, and methanol. They conclude that roughly two thirds of the enhanced acidity of vinyl alcohol relative to methanol is due to resonance effects (ie pi delocalization) and the rest is explained by inductive effects. If these trends would hold true with phenol vs MeOH or CyOH, the inductive effects would contribute ca 2 pKa units to the difference and the delocalization should then explain the remaining 4 pKa units.
March 14th, 2007 at 6:17 pm
This is really strange - Paul, could you delete my comments 55 and 56
1) Solvation plays a role in all acid-base reactions. The trend with hydrogen halides (HF weakest, HCl, HBr, HI (strongest)), however, persists also in the gas phase:
http://dx.doi.org/10.1021/jp0116407
2) Yes, accordingly - but not by a factor of 10^6! The figure for khi (electronegativity) that Evans gives for sp2 carbon on his own lectures is 2.8. If electronegativity alone would play a role in determining the acidity of acids of the type H-O-X, the acidities would increase in the order
H-O-CH3 - H-O-CH=CH2, H-O-Ph - (H-O-NR2) - H-O-O-R - H-O-F
Let’s take a look at the pair HOMe - HOPh and HOPh - HOOH. In the first pair, the electronegativity difference is 2.8-2.5 = 0.3 and this, according to the Evans explanation, translates to ca 10^5 - 10^6-fold increase in Ka. For the latter pair, the electronegativity difference is much greater, 3.5 (O) - 2.8 (sp2 C) = 0.7, and accordingly hydrogen peroxide should be much more acidic than phenol.
But it is not! The pKa of hydrogen peroxide is ca 11.5, it is in fact _less_ acidic than phenol.
So something is wrong with the model. I would say the problem lies in not giving delocalization (”resonance”) the role it deserves.
March 14th, 2007 at 7:52 pm
Little things, like writing clearly, will make a difference. You’re asking a lot of your readers to have to decipher a poorly written paper. When it comes to demonstrating your competancy in science don’t excpect anyone to give you the benefit of the doubt…the same goes for seminars and lectures.
The phenol issue reminds me of a similar debate concerning the acidity carboxylic-acids versus alcohols that was being fought in the literature more than a decade ago.
March 14th, 2007 at 9:06 pm
I noticed a grammar error in one of Grubbs’ recent Org Lett papers. Check Figure 4. Okay, yes, I AM guilty of putting Grubbs on a pedestal, but based on this and that Evan’s article I think it wise to place the blame on Org Lett’s copy editors and not necessarily on the original authors. Something like the error in Grubbs’ paper would not escape the omniscient eye of The Man.
March 14th, 2007 at 9:08 pm
I meant spelling error. (I suppose it could be construed as both…)
March 14th, 2007 at 9:13 pm
So you contend that there’s a rogue copy editor at Org. Lett. who’s inserting small grammatical errors into papers by big-name chemists? :O
March 14th, 2007 at 10:53 pm
No, I’m saying they’re not doing their jobs correctly. As some have pointed out, the blame might be more accurately placed upon the copy editors and not necessarily on the authors.
March 14th, 2007 at 10:55 pm
Beckmesser, Beckmesser, where are u going to ?
March 14th, 2007 at 11:09 pm
I see, so the authors don’t share the responsibility of correcting errors in the manuscript.
March 14th, 2007 at 11:22 pm
No, that’s why we have the language polishing service of Angewandte, or in case you have never published there, even in JACS. They catch your errors and don’t try to be much better than you.
Share your responsibilities, Paul, and win. But, I admit, getting a Ph.D. is not about that.
March 14th, 2007 at 11:59 pm
Sure the authors have to share some of the blame, but the reason copy editors exist is to keep these problems from happening. Articles that come out with egregious/obvious errors are directly the fault of copy editors not doing their job- they are the last people to read the print before it goes to press. I don’t know how ACS Publications handle their copyediting process (hopefully I’ll get to find out soon…) but that’s how other forms of the press use copy editors. From Wikipedia:
“The copy editor’s job may be summarized in the 5 Cs: to make the copy clear, correct, concise, comprehensible, and consistent. Copy editing typically entails correcting spelling, punctuation, grammatical and semantic errors; ensuring the typescript adheres to the publisher’s house style; adding standardized headers, footers, headlines and so on. ”
If you want to place the blame directly on the authors, fine, part of it belongs there for not catching things like that themselves. But part of the blame belongs squarely on the journal themselves. The “Evan’s” mistake makes more than just the authors look bad- it makes the journal look bad, too- that’s one of the reasons copy editors exist, as a last line of defense, to save everyone’s ass from seething bloggers.
March 15th, 2007 at 12:05 am
I wonder if PJS and ABS3 are reading these posts.
March 15th, 2007 at 12:21 am
Why all the hating on the copy desk?
I haven’t the foggiest idea how copyediting works at the journals (and we love our copy editors at C&EN), but copyeditors are often the journalism world’s equivalent of grad students : They work incredibly hard on tedious assignments, catching dumb mistakes that authors shouldn’t have made in the first place. No one notices or praises them for the 10,000 mistakes they did catch. But when they miss one little misplaced apostrophe in a sea of text, suddenly they’re not doing their jobs.
Are copy editors really the most appropriate target for such vitriol?
March 15th, 2007 at 12:27 am
bla,bla,bla
the matter is, if you have been a high school A+++ student and now at Harvard, Oxford, Heidelberg or anywhere, you need to learn what the world is really like
March 15th, 2007 at 12:36 am
Paul, just for the grammar, should I have said “alike”, or only “like” ??
March 15th, 2007 at 12:41 am
March 15th, 2007 at 12:42 am
right you say
March 15th, 2007 at 12:47 am
you forgot the “a” in your comic, but yes, you are right !
your English sounds like that of a Turk
March 15th, 2007 at 1:06 am
My intention certainly wasn’t vitriol, Beth. I have too many journalism major friends who would kill me for insulting that part of the job. It’s just reality, I guess- I’ve had discussions with journalism people who said, point-blank, if there’s a blatant problem with the output, it’s the copy editor’s fault. That’s just the reality as I’ve been told as it is. Of course, I object to making a big deal about it in the first place, but if you are, place it where it need be placed- on everyone who could have potentially fixed the error.
I try hard not to be an asshole. Sometimes.
March 15th, 2007 at 1:08 am
Yeah, there were massive grammar foibles in that last comment. My bad.
March 15th, 2007 at 1:15 am
Paul, just for the theory, since you’re exposing yourself here so much, I assume you’re only a computer simulation, and have no soul. You cannot be real, otherwise you would get really angry.
March 15th, 2007 at 1:28 am
Don’t worry Ex, nobody proofreads stuff on the Internet.
And Wolfie, you know that you’re my favorite commenter, right? It’s for the same reasons that Colonel Klink was my favorite character on Hogan’s Heroes.
March 15th, 2007 at 1:34 am
will have to think about that
March 15th, 2007 at 1:39 am
Here’s an episode on YouTube. Does Germany have color television yet?
http://www.youtube.com/watch?v=1NZlex7SH6Y
March 15th, 2007 at 1:57 am
can’t watch it now, desert island has nothing like that
tomorrow is another day
March 15th, 2007 at 4:45 am
To Wolfie,
I have been noticing your concern for Paul’s Phd. Please understand, Wolfie, that (almost, I assume, w/hi-t/e sid/e-s cannot be an exception) every PI helps dumb students to get a PhD (and many papers), while they often accademically hostile to promising students. The fact of matter is that many of the former category students understand it very late, some never, like you because they became more dumber than their PhD days.
March 15th, 2007 at 6:27 am
Hey Beth: Tell the art staff at C&EN that the March 12th cover was very cleverly done. I loved the transparent title lettering against the Chinese flag. Subtle and cool.
March 15th, 2007 at 12:33 pm
“every PI helps dumb students to get a PhD (and many papers), while they often accademically hostile to promising students”
Wow, that sucks. So he’s just being nice to me because I’m dumb and get results which produce papers. I’ve suspected it for a long time, but since I’m stupid, the realization was slow in coming. Thanks for the info though. Now I shall get my revenge…
March 15th, 2007 at 4:37 pm
Actually, this might sound arrogant, but you get exasperated when you talk to a piece of wood for a long time. So, I really doubt that ‘every PI helps dumb students get a PhD and many papers’. Unless they are masochistic. Which I guess, is what helps you get tenure. But no, most PIs help dumb students to get a Masters, would probably be a better statement. Then the dumb students have better job prospects as well. Go figure…
March 16th, 2007 at 12:25 pm
Hey Paul,
One of the most storied labs in synthetic organic chemistry has done it again in Org Lett:
http://dx.doi.org/10.1021/ol070163t
There’s a spelling error in the first paragraph that any spell-check would have caught, and on the second page a paragraph ends without a period.
Super job!
March 16th, 2007 at 2:27 pm
Nice find. Once an accident…twice a coincidence…three times would be a trend.
March 16th, 2007 at 3:10 pm
See?!? My tinfoil hat and I were right! It is a conspiracy!!!!11oneone
March 17th, 2007 at 7:37 pm
“more dumber” must be the final word here
March 23rd, 2007 at 2:01 pm
Paul,
Regarding typos in type-set publications: Most errors come from the type-setting and can be hard to catch in proof-reading. If you’ve written it and rewritten it, your mind knows the word is ‘stitch’ without processing the entire word printed as ‘stich’. Have someone new read it out loud to you while you look at the original, or even better read it backwards! Punctuation is still a problem if the reader is not good at it.
You have to be careful about throwing stones at grammar. Most of us have glass windows if someone looks at them. My dissertation reading catches numerous dangling gerund phrases and incorrectly punctuated non-restrictive ‘which’ clauses. So I thought I’d check your publications! Here’s what I found:
http://www.paulbracher.com/lab.....s/pub2.pdf
“Using nitrogen-purged solutions, both fingerprints, namely, decay of CuP+¥ absorption at 660 nm and decay of C60 ¥- absorption at 1040 nm, reveal a decay time constant
of 140……………”
Dangling gerund. Fingerprints can’t use nitrogen-purged solutions.
“FAB mass spectral data were obtained at the Michigan State University Mass Spectrometry Facility which is supported…………”
Non-restrictive ‘which’ clause needs a comma unless MSU has a MS Facility that is not supported.
http://www.paulbracher.com/lab.....s/pub3.pdf
“By changing the nature of the linkage between the ZnP and Cu(I)-phen moiety in the macrocyclic precursors to rotaxanes 2 and 3, the distance between the centers of positive and negative charge………”
How did ‘distance’ change the nature of the linkage? Meaning is not mangled, but incorrect grammar!
http://www.paulbracher.com/lab.....s/pub1.pdf
“(the other three meso positions are occupied by 3,5-di-tert-butylphenyl groups which improve solubility in common organic solvents…………”
Needs a comma unless some 3,5-di-tert-butylphenyl groups do not improve solubility!
“To date, no artificial system incorporating fullerenes has been reported which is able to accomplish the same objectives.”
‘which’ clause is dangling and not punctuated
“The problem here is to synthesize molecular arrays analogous to 48 which can be unidirectionally inserted…………”
Non-restrictive which clause needs a comma
“Using ESFF and CVFF force fields, these observations [39] have been exactly reproduced computationally………”
“Using techniques discussed in section 3.1, it was shown that (a) excitation of…………”
“Using methodology adapted from that used by Maggini, Guldi and coworkers [75] to prepare analogous [Ru(bpy)3]2+ dyads, androstan-3-one was first linked to C60……”
“Using varying applied DC voltages, the aniline–C60 dyad………”
Four examples of dangling gerunds.
March 23rd, 2007 at 3:37 pm
Yup, you’re right. I have to say that George is the main reason my grammar has improved big time in grad school. When I read through some of the stuff I’ve written in the past (those three papers were from my undergrad days), I cringe at some of the mistakes. I find the errors (whether in grammar or bad style) like those you mentioned very embarrassing. There is no excuse for making them; you just admit you’re wrong and try to improve. I read through Strunk and White twice a year, cover-to-cover, and proofread things with care. While this is extreme, I think that too many people don’t give a damn at all.
March 23rd, 2007 at 5:36 pm
Also very much worth reading “Eats, shoots and leaves” by Lynne Truss
March 23rd, 2007 at 6:13 pm
I knew someone who was on his twelveth(?) draft of a GMW paper. Large parts of the editing go towards experimental refinements and data needing to be acquired, but much of it is refinement in the writing and logic of the papers. If one writes enough papers with Prof. Whitesides, eventually some of the reasons for the editing and the rules underlying them will sink in. This would seem to be part of the job that professors are supposed to do - technical skills are more easily acquired (and more transient) than the ability to communicate ones’ work clearly and logically (and perhaps to work more logically as well).
March 26th, 2007 at 2:01 pm
Strunk and White (The Elements of Style) pretty clearly says it should be Evans’s and Grubbs’s (not Evans’ and Grubbs’) when referring to singular possessive.
So when Paul wrote, “For those interested, these data come from Evans’ Chem 206 lecture notes” he was ironically just as bad as the original paper he was slamming (”the misplaced apostrophe in “Evan’s” was the most aggravating.”) The only people that get an exception to this rule are biblical (ie: Jesus’ and Moses’).
Don’t get me wrong, Evans and Grubbs are good… but I’m not sure they deserve the biblical exception to the rule.
March 26th, 2007 at 2:17 pm
I was wondering whether anyone would bring up the letter of S&W’s law. My thought on the subject is that time passed them by. “Evans’s” looks and sounds stupid.
March 26th, 2007 at 5:03 pm
S+W makes a lot of sense - while the multiple Ss when the singular possessor has an s at the end of his name sounds stupid, the use of the possessive in that form readily differentiates singular possessives from plural possessives. The addition of another rule in possesives when people can barely distinguish between possessives and contractions on a consistent basis doesn’t make a whole lot of sense, particularly when it makes writing less clear as well.
English is a hard language to justify anything by how well or badly it sounds, considering its less than consistent pronunciation rules.
March 27th, 2007 at 9:27 am
I think that the Chicago Manual of Style, which is about 1000 times more definative than Strunk and White, states that nouns ending in “s” should simply add an apostrophe, e.g. Evans’ and never, ever Evans’s. An example they give follows from an answer to a question posted:
Possessives and Attributives
Q. A friend and I were looking at a poster that read “guys apartment.” I believe it should read “guys’ apartment.” She claims that it should read “guys’s apartment” and that the CMOS specifically gives the example of “guys’s” to make “guys” possessive. I looked through every section on possessives and did not find the word “guys’s” or any rule that would make this correct. Some people say “you guys’s apartment”—did I overlook the word “guys’s” as used in the attributive position? (I don’t think I did.)
A. “Guys’s” is acceptable in the way that “youse guys” is acceptable; that is, neither is yet recognized as standard prose, and if your friend can find it in CMOS, I’ll eat my hat. Plural nouns that end in s (like “guys”) don’t add another s to form the possessive, e.g., the students’ lounge. “Guys’ apartment” is the standard spelling. If you want to make “guys” attributive, you can get away without the apostrophe, but you might test the idea with a plural noun that doesn’t end in s to see whether the attributive actually works: I doubt you’d write “the women apartment,” so you shouldn’t write “the guys apartment” either. And shame on your friend. It must make you wonder what else she’s capable of.
http://www.chicagomanualofstyle.org/home.html
March 27th, 2007 at 11:05 am
“Some people say “you guys’s apartment””
I believe almost every says it, not just some. Likewise, almost everyone will say “Evans’s”. However, it is not correct written form. The correct written form is “guys’ apartment”.
Evan is just one guy, but his family has a lot of Evanses. So you would write, “I’m goin’ to the Evanses’ house to talk shop ’bout my lattest JACS comm with da tribe.”
But if you were reading a JACS comm, where Evan was the senior author, you’d write, “I’m just knockin’ back a few while ab-sorbin’ some serious shit form da latest Evan’s JACS comm. Peace.”
March 28th, 2007 at 4:16 pm
I’m actually not sure if Eugene’s post was a joke… I don’t get jokes.
For the sake of clarity: His name is David Evans (not Evan), and because it refers to a singular person it is a singular noun (as opposed to the plural noun: guys).
I agree that you should not write or say “guys’s apartment.” However, you most certainly should write Evans’s (and Grubbs’s).
